Page 13 - CAR - Levigatori ENG

Automatic expansions mandrels Mandrels type EMO

type COLMER “S”
Diameter range: 115 ÷ 500 mm

DEPLIANT

Extension stone-holder Extension stone-holder
and shoes type "N" and shoes type "NN"
EMO are very versatile Mandrels,
they use expansion heads type Mandrel Code Honing diameters Max length (standard)
range
COLMER so they have the same
Stone set "R7" Stone set "R7" honing diameters range. EMO EMO 29 Ø 25÷33 mm 2000 mm
Mandrels are assembled onto vertical
and horizontal honing machines and EMO 44 Ø 31÷44 mm 3000 mm
can achieve honing lengths until
Steadiness rotation support 4 mt., using personalized extension EMO 66 Ø 44÷66 mm 3000 mm
type "S" bars which have “sphere” and
“flanged” connections (see pictures EMO 350 Ø 63÷500 mm 4000 mm
EXPANSION SYSTEM “N” AND “S” TO HONE DIAMETER OVER 139 MM below).

B
A

DETAIL A
DETAIL B
Series of extension
Series of extension Serie of Rotation
Honing Diameter range stone-holder and shoes DETTAGLIO B
stone-holder and shoes Supports type “S” SCALA 2 : 4.2
double

A
B
DETAIL B
DETAIL A

Example of EMO 66.3: D.44-66mm L=3000mm “sphere” Example of EMO 350F.3: D.63-500mm L=3000mm “flanged”

DETTAGLIO A
SCALA 2 : 4.2

CAR s.r.l. - Italy - Tel. +39 039.69 59 161 - Fax +39 039.69 57 330 - E-mail: info@carsrl.it - www.carsrl.it
